CMOS Sensor | Product Line up
Product Line up
2M-5M
-
High dynamic range(HDR) function with 120dB.
1/1.8 inch 2.12M Pixel.
-
High dynamic range(HDR) function with 120dB.
1/2.32 inch 2.82M Pixel.
-
High dynamic range(HDR) function with 120dB.
1/1.8 inch 2.12M Pixel.
-
Global shutter.
Exposes all pixels at the same time.
2/3inch 5.33M Pixel.
-
High sensitivity, low noise.
Pixel size 19um.
35mmFull Size 2.76M Pixel.
-
NIR sensitivity is improved compared to conventional models.
35mmFull Size 2.12M Pixel.
10M-50M
-
Pixel size is compact.(1.86um)
High sensitivity. Support 4K.
1/1.7inch 12M Pixel.
-
Supports video and still Image.
1inch12M Pixel.
-
This sensor is capable of 4K2K readout at 120 fps.
Super 35mm 10.8M Pixel.
-
Global shutter,High sensitivity Pixel size 6.4um.
35mm Full Size 19M Pixel.
-
This sensor is a 4K2K pixel global shutter.
Super 35mm 10.3M Pixel.
100M-
| Product | Shutter Type |
Image Size |
Resolution | Pixel Size (μm) |
Filter Type | IF | Max Frame Rate (fps) |
Application |
|---|---|---|---|---|---|---|---|---|
| LI7050SA | Rolling | 1/1.8" | 2.1M | 4.1 | RGB | MIPI CSI2 | 60 | Surveillance |
|
NEW |
Rolling | 1/1.8" | 2.1M | 4.1 | Mono RGB |
MIPI CSI2 | 60 | Surveillance |
| 35mm FHDXS |
Rolling | 35mm Full Size | 2.7M | 19 | Mono RGB |
Analog | 115 (FullHD) | Space science Surveillance Biomedical imaging |
| LI3030SA | Rolling | 35mm Full Size | 2.7M | 19 | Mono RGB RGB-IR |
Analog | 115 (FullHD) | Space science Surveillance Biomedical imaging |
| LI7060SA | Rolling | 1/2.3" | 2.8M | 3.2 | RGB | MIPI CSI2 | 60 | Surveillance |
| LI5040SA | Global | 2/3" | 5M | 3.4 | Mono RGB RGB-IR |
LVDS | 120 | Industry |
|
NEW |
Global | Super35mm | 10.3M | 6.4 | RGB | LVDS | 60 | Biomedical imaging Cinema |
| LI7080SA | Rolling | Super35mm | 10.8M | 6.4 | RGB | LVDS | 120 | Surveillance Cinema |
| LI7030SA | Rolling | 1" | 12M | 3.2 | RGB | LVDS | 60 (4K2K) | Surveillance |
| LI5030SA | Global | 35mm Full Size | 19M | 6.4 | Mono RGB RGB-IR Naked |
LVDS | 60 (5.7K3.2K) | Space science Surveillance Electronic microscope |
| LI8010SA (120MXS) |
Rolling | APS-H | 120M | 2.2 | Mono RGB RGB-IR |
LVDS | 9.4 | Industry |
| LI8020SA | Rolling | APS-H | 250M | 1.5 | Mono RGB |
LVDS | 5 | Surveillance Industry |
